Why another supervision suite ?
Supervision suites are becoming quite common. Today, we already have:
- Good (?) old System V init, which can be made to supervise services if you perform /etc/inittab voodoo.
BSD init can also be used the same way with the /etc/ttys file, but for some reason, nobody among BSD
developers is using /etc/ttys to this purpose, so I won't consider BSD init here.
- daemontools, the pioneer
- daemontools-encore, Bruce Guenter's upgrade to daemontools
- runit, Gerrit Pape's suite, well-integrated with Debian
- perp, Wayne Marshall's take on supervision
- Integrated init systems providing a lot of features, process supervision being one of them.
For instance, Upstart, MacOS X's
and Fedora's systemd.
Why is s6 needed ? What does it do differently ? Here are the criteria I used.
Supervision suites should not wake up unless notified.
- System V init fails the test: it wakes up every 5 seconds, for the reason that
/dev/initctl might have changed.
- daemontools fails the test: it wakes up every 5 seconds to check for new services.
- daemontools-encore does the same.
- the current version of runit fails the test: it wakes up every 14 seconds. But this is a workaround for a bug in some Linux kernels;
there is no design flaw in runit that prevents it from passing the test.
- perp works.
- Upstart works. I have no idea what other integrated init systems do: it's much too difficult to strace them
to see exactly where they're spending their time, and when it is possible, the trace output is so big that it's
hard to extract any valuable information from it.
- s6 works. The -t option to s6-svscan makes it check its services
with a configurable timeout; by default, this timeout is infinite, i.e. it
never wakes up unless it receives a command via s6-svscanctl.
Supervision suites should provide a program that can run as process 1.
- System V init is process 1, so no problem here.
- Integrated init systems, by definition, provide a process 1.
- daemontools was not designed to take over init, although
it can be made to work with
enough hacking skills. Same thing with daemontools-encore.
- runit provides an init functionality, but the mechanism is
separate from the supervision itself; the runit process, not the
runsvdir process, runs as process 1. This lengthens the supervision
- perp was not designed to run as process 1. It probably could be made to work too
without too much trouble.
- s6-svscan was designed from the start to be run as process 1, although it
does not have to.
Supervision suites should be bug-free, lightweight and easy to understand.
- daemontools, daemontools-encore, runit and perp all qualify. All of this is excellent quality
- System V init is understandable, and reasonably lightweight; but it is still
too big for what it does - poorly. The /etc/inittab file needs to be parsed;
that parser has to be in process 1. There is support in process 1 for the whole
"runlevel" concept, which is a primitive form of service management. The same
executable handles all 3 stages of the machine's lifetime and does not separate
them properly. All in all, System V init does its job, but is showing its age
and nowadays we know much better designs.
- This is where integrated init systems fail, hard. By wanting to organize
the way a the machine is operated - so, machine state management - in the
same package as the init and process supervision system, they add
incredible complexity where it does not belong.
What those systems fail to recognize is that process supervision, rooted in
process 1, is a good thing, and machine management is also a good thing, but
those are two different functions, and a good init system
needs, and should, only provide process supervision, in
order to keep such a crucial piece of code as easy to maintain as possible.
Machine management can be added on top of a process supervision
suite, in a different package, and it has nothing to do with process 1.
- Upstart uses ptrace to watch its children fork(), and links
process 1 against libdbus. This is insane.
Process 1 should be absolutely stable, it should be guaranteed
to never crash, so the whole of its source code should be under control. At
Upstart's level of complexity, those goals are outright impossible to achieve,
so this approach is flawed by design. It is a shame, because the concepts
and ideas behind Upstart are good and sound; it's the
implementation choices that are its downfall.
- launchd suffers from the same kind of problems. Example: Services
running under launchd must be configured
XML; the launchctl process interprets the XML, converts it into a
key-value store (which is strictly
less powerful than XML, so why do they even use XML in the first place?)
and sends it to launchd via a Mach-specific IPC. Process 1 needs to be
linked against the library that handles the Mach IPC, it needs to decode
the key-value store, and use it to run and supervise a daemon. And it
needs to keep everything in memory. This is
a lot more complex and resource-consuming than it needs to be.
- systemd is much, much worse than the other ones, and a real danger
for the future of GNU/Linux. I have a special page
dedicated to it.
- s6, which has been designed with embedded environments in mind, tries
harder than anyone to pass this. It tries so hard that s6-svscan
and s6-supervise, the two long-running programs that make the
supervision chain, do not even allocate heap memory, and their main
program source files are less than 500 lines long.
Supervision suites should provide a basis for high-level service management.
- Neither System V init, daemontools, runit or perp
provides any hooks to wait for a service to go up or down. runit provides a
waiting mechanism, but it's based on polling, and the ./check script
has to be manually written for every service.
- daemontools-encore qualifies: the notify script can be used for
inter-service communication. But it's just a hook: all the real notification
work has to be done by the notify script itself, no notification framework is
- Integrated init systems provide high-level service management
themselves. Again, this is not good design: service management has nothing
to do with init or process supervision, and should be implemented on top
of it, not as a part of it.
- s6 comes with an event notification
library, and command-line tools based on this library, thus providing a simple
API for future service management tools to build upon.
- s6-svscan and s6-supervise are entirely asynchronous.
Even during trouble (full process table, for instance), they'll remain reactive
and instantly respond to commands they may receive. s6-supervise has
even been implemented as a full deterministic finite automaton, to ensure it
always does the right thing under any circumstance. Other supervision suites
do not achieve that for now.
- daemontools' svscan
maintains an open pipe between a daemon and its logger, so even if the daemon,
the logger, and both
die, the pipe is still the same so no logs are lost, ever, unless
svscan itself dies.
- runit has only one supervisor, runsv,
for both a daemon and its logger. The pipe is maintained by runsv.
If the runsv process dies, the pipe disappears and logs are lost.
So, runit does not offer as strong a guarantee as daemontools.
- perp has only one process, perpd,
acting both as a "daemon and logger supervisor" (like runsv) and as a
"service directory scanner" (like runsvdir). It maintains the pipes
between the daemons and their respective loggers. If perpd dies, everything
is lost. Since perpd cannot be run as process 1, this is a possible SPOF for
a perp installation; however, perpd is well-written and has virtually no risk of
dying, especially compared to process 1 behemoths provided by integrated
- Besides, the runsv model, which has to handle both a daemon
and its logger, is more complex than the supervise model (which
only has to handle a daemon). Consequently, the runsvdir model is
simpler than the svscan model, but there is only one svscan
instance when there are several runsvs and supervises.
The perpd model is obviously the most complex; while very understandable,
perpd is unarguably harder to maintain than the other two.
- So, to achieve maximum simplicity and code reuse, and minimal memory
footprint, s6's design is close to daemontools' one.
And when s6-svscan is run as process 1,
pipes between daemons and loggers are never lost.
All in all, I believe that s6 offers the best overall implementation of a
supervision suite as it should be designed. At worst, it's just another
take on daemontools with a reliable
base library and a few nifty features.
